Shimano Deore M5100 2-Speed Front Derailleur

Description

SHIMANO DEORE – Front Derailleur – SIDE SWING – Clamp Band Mount – 2×11-speed

Delivering quiet and smooth shifting, SHIMANO’s FD-M5100 2×11 front derailleurs feature SHIMANO’s new SIDE SWING technology. The new design offers enhanced cable routing, light action, and increases clearance for large wheels and short chain stays.

FEATURES

Smooth and quiet front shifting on the trail

More powerful outward shifting

Wider traction range reduces chain rub for rear suspension bikes

Extra wide range with front double 36-26T

Wider tire clearance

Compatible with 2.3-inch tire on wider rims

One spec for 48.8 mm & 51.8 mm chainline

*M type mount requires adapter (ø34.9 mm)

PRODUCT SPECIFICATIONS

MODEL NO	FD-M5100-M
SERIES	DEORE M5100 Series
Color	Series color

Action_SIDE SWING	✔
Angled clamp band design	✔
Angled stroke adjust screw	✔
Cable route type_Front-Pull	✔
Chain line (mm)	48.8/51.8
Chain stay angle (deg.)	64-69
Compatible chain	LINKGLIDE, HG 11-speed
Link bushings	4
Mount_Clamp Band (mm)_31.8	X (w/ M size adapter)
Mount_Clamp Band (mm)_34.9	✔
Top gear teeth	38T
Total capacity	10T
Front speeds	2
Rear speeds	11
